Loj: φ6-φ36
Qib ： 4.8，8.8
Nto: ZP / HDG / BLSCK / DACROMET
Cov Lus Qhia Tshwj Xeeb | φ3.2 | φ3.7 | φ4.3 | φ5.3 | φ6.4 | φ7.4 | φ8.4 | φ10.5 | φ13 | φ15 | φ17 | |
M | Sib nug moo ntsia liaj qhov rooj | M3 | M3.5 | M4 | M5 | M6 | M7 | M8 | M10 | M12 | M14 | M16 |
d | Yam tsawg kawg nkaus | 3.2 | 3.7 | 4.3 | 5.3 | 6.4 | 7.4 | 8.4 | 10.5 | 13 | 15 | 17 |
Tus nqi siab kawg | 3.38 | 3.88 | 4.48 | 5.48 | 6.62 | 7.62 | 8.62 | 10.77 | 13.27 | 15.27 | 17.27 | |
dс | Tus nqi siab kawg | 7 | 8 | 9 | 10 | 12 | 14 | 16 | 20 | 24 | 28 | 30 |
Yam tsawg kawg nkaus | 6.64 | 7.64 | 8.64 | 9.64 | 11.57 | 13.57 | 15.57 | 19.48 | 23.48 | 27.48 | 29.48 | |
h | nominal | 0.5 | 0.5 | 0.8 | 1 | 1.6 | 1.6 | 1.6 | 2 | 2.5 | 2.5 | 3 |
Tus nqi siab kawg | 0.55 | 0.55 | 0.9 | 1.11 | 1.8 | 1.8 | 1.8 | 2.2 | 2.7 | 2.7 | 3.3 | |
Yam tsawg kawg nkaus | 0.45 | 0.45 | 0.7 | 0.9 | 1.4 | 1.4 | 1.4 | 1.8 | 2.3 | 2.3 | 2.7 | |
Nyhav / mpcs (kg) | 0.119 | 0.155 | 0.308 | 0.443 | 1.02 | 1.39 | 1.83 | 3.57 | 6.27 | 8.62 | 11.3 | |
Cov Lus Qhia Tshwj Xeeb | φ19 | φ21 | φ23 | φ25 | φ27 | φ28 | φ29 | φ31 | φ33 | φ34 | φ36 | |
M | Sib nug moo ntsia liaj qhov rooj | M18 | M20 | M22 | M24 | M26 | M27 | M28 | M30 | M32 | M33 | M35 |
d | Yam tsawg kawg nkaus | 19 | 21 | 23 | 25 | 27 | 28 | 29 | 31 | 33 | 34 | 36 |
Tus nqi siab kawg | 19.33 | 21.33 | 23.33 | 25.33 | 27.33 | 28.33 | 29.33 | 31.39 | 33.62 | 34.62 | 36.62 | |
dс | Tus nqi siab kawg | 34 | 37 | 39 | 44 | 50 | 50 | 50 | 56 | 60 | 60 | 66 |
Yam tsawg kawg nkaus | 33.38 | 36.38 | 38.38 | 43.38 | 49.38 | 49.38 | 49.38 | 55.26 | 58.8 | 58.8 | 64.8 | |
h | nominal | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 4 | 5 | 5 | 5 |
Tus nqi siab kawg | 3.3 | 3.3 | 3.3 | 4.3 | 4.3 | 4.3 | 4.3 | 4.3 | 5.6 | 5.6 | 5.6 | |
Yam tsawg kawg nkaus | 2.7 | 2.7 | 2.7 | 3.7 | 3.7 | 3.7 | 3.7 | 3.7 | 4.4 | 4.4 | 4.4 | |
Nyhav / mpcs (kg) | 14.7 | 17.2 | 18.3 | 32.3 | 43.7 | 42.3 | 40.9 | 53.6 | 77.4 | 75.3 | 94.3 | |
Nyhuv:
1. Ua kom thaj tsam sib tiv tauj ntawm hau ntswj thiab lub tshuab.
2. Tshem tawm qhov kev puas tsuaj rau saum npoo ntawm lub tshuab thaum nplooj ntoo hlav tawm cov ntsia hlau. Thaum siv, nws yuav tsum yog lub ntaub qhwv rau lub caij nplooj hlav thiab lub tiaj tiaj. Daim txiag tiaj yog nyob ib sab ntawm lub tshuab, thiab lub caij nplooj hlav hlav yog nruab nrab ntawm cov ntaub qhwv tiaj thiab cov txiv ntoo.
Cov ntaub qhwv tiaj tiaj yog daim nyias nyias ntawm ntau cov qauv siv los txo kev sib txhuam, tiv thaiv to, cais tawm, tiv thaiv xoob, lossis faib siab. Ntau cov ntaub ntawv thiab cov qauv muaj cov khoom sib xyaw, uas yog siv los ua ntau cov haujlwm zoo sib xws. Txwv los ntawm cov khoom siv thiab cov txheej txheem ntawm cov xov fasteners, txhawb cov saum npoo ntawm pob tw thiab lwm yam fasteners tsis loj. Yog li, thiaj li yuav txo qis qhov kev nyuaj siab ntawm qhov siab-cov kabmob ntawm qhov chaw txhawm rau tiv thaiv cov nplaim ntawm cov ntu sib txuas, cov ntaub qhwv tiaj tiaj siv.
Cim npe nrov: din125 tiaj tus ntxhua khaub ncaws, Suav teb, lwm tus neeg muag khoom, hoobkas, lag luam, customized, lag luam wholesale, luv nqi, quotation, tsis tshua muaj nqe, hauv Tshuag, dawb qauv
