Qhov loj me ： M3-M56
Qib ： 4，6，8，10
Nto ： ZP, HDG, DUB, DACROMET
Xov specification | M3 | M4 | M5 | M6 | M7 | M8 | M10 | M12 | M14 | M16 | M18 | |
d | ||||||||||||
p | ntxhib hniav | 0.5 | 0.7 | 0.8 | 1 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2 | 2.5 |
hniav zoo | / | / | / | / | / | 1 | 1.25 | 1.5 | 1.5 | 1.5 | 2 | |
hniav zoo heev | / | / | / | / | / | / | 1 | 1.25 | / | / | 1.5 | |
k | Tshaj plaws=nominal | 2.4 | 3.2 | 4 | 5 | 5.5 | 6.5 | 8 | 10 | 11 | 13 | 15 |
yam tsawg kawg nkaus tus nqi | 2.15 | 2.9 | 3.7 | 4.7 | 5.2 | 6.14 | 7.64 | 9.64 | 10.3 | 12.3 | 14.3 | |
s | Tshaj plaws=nominal | 5.5 | 7 | 8 | 10 | 11 | 13 | 17 | 19 | 22 | 24 | 27 |
yam tsawg kawg nkaus tus nqi | 5.32 | 6.78 | 7.78 | 9.78 | 10.73 | 12.73 | 16.73 | 18.67 | 21.67 | 23.67 | 26.16 | |
e | yam tsawg kawg nkaus tus nqi | 6.01 | 7.66 | 8.79 | 11.05 | 12.12 | 14.38 | 18.9 | 21.1 | 24.49 | 26.75 | 29.56 |
* | - | - | - | - | - | - | - | - | - | - | - | |
Nyhav / mpcs (kg) | 0.384 | 0.81 | 1.23 | 2.1 | 3.12 | 4.5 | 10.15 | 14.8 | 22.6 | 29.3 | 40.3 | |
Xov specification | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | M42 | M45 | M48 | |
d | ||||||||||||
p | ntxhib hniav | 2.5 | 2.5 | 3 | 3 | 3.5 | 3.5 | 4 | 4 | 4.5 | 4.5 | 5 |
hniav zoo | 2 | 2 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 | |
hniav zoo heev | 1.5 | 1.5 | / | / | / | / | / | / | / | / | / | |
k | Tshaj plaws=nominal | 16 | 18 | 19 | 22 | 24 | 26 | 29 | 31 | 34 | 36 | 38 |
yam tsawg kawg nkaus tus nqi | 14.9 | 16.9 | 17.7 | 20.7 | 22.7 | 24.7 | 27.4 | 29.4 | 32.4 | 34.4 | 36.4 | |
s | Tshaj plaws=nominal | 30 | 32 | 36 | 41 | 46 | 50 | 55 | 60 | 65 | 70 | 75 |
yam tsawg kawg nkaus tus nqi | 29.16 | 31 | 35 | 40 | 45 | 49 | 53.8 | 58.8 | 63.1 | 68.1 | 73.1 | |
e | yam tsawg kawg nkaus tus nqi | 32.95 | 35.03 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | 71.3 | 76.95 | 82.6 |
* | - | - | - | - | - | - | - | - | - | - | - | |
Nyhav / mpcs (kg) | 59.3 | 66.3 | 93.2 | 143.8 | 205.8 | 256.9 | 337.7 | 449.7 | 652 | 800 | 977 | |
Hex txiv ntoo yog rau cov ntawv thov dav dav thiab siv nrog bolts thiab txuas ntawm tib qhov chaw tiav. Cov txiv ntoo feem ntau siv, lawv feem ntau pom nyob hauv lawj thiab laj kab tsev. Cov hu ua qhov loj me yog txoj kab uas hla sab hauv thiab cov xov tooj ntawm ib nti lossis xov xov.
* Sab hauv xov thiab muaj hex tsav rau yuav luag txhua cov ntawv thov dav dav
* Muaj peev xwm siv tau nrog ib qho fastener nrog tshuab ntsia hlau xov
* Qhov chaw muaj cov xov loj ntxhib me me
* Stainless hlau tag rau kev ua kom zoo tshaj plaws-hauv-kev txhim kho corrosion
Hex txiv ntseej specifications:
1. Lub qhov ncauj hexagonal tso cai rau tus pin sib npaug lossis qhov xeb.
2. Xaus chamfer d.
3. Qhov ntev ntawm cov xov tsis tiav U.
4. Lub ntsej muag sab saum toj ntawm lub taub hau tuaj yeem muab puag ncig los yog chamfered, uas yog xaiv tau los ntawm lub chaw tsim khoom.
5. Lub ntug qhov kawg tuaj yeem hloov mus los yog ua ciab rau Dw, tab sis yuav tsum tsis muaj qhov faus.
FAQ:
1. Q: Li cas txog koj tus nqi?
A: Peb lub tuam txhab yog cov chaw tsim tshuaj paus kev tshaj lij, yog li peb tuaj yeem muab koj nqi Hoobkas.
2. Q: Koj ua li cas tswj koj qhov zoo?
A: Cov khoom yuav mus dhau los ntawm qhov txheej txheem sorting nyob rau hauv qhov chaw ua haujlwm tshawb pom qhov zoo, uas tuaj yeem lav tus nqi dhau ntawm cov khoom lag luam dhau los tuaj yeem ncav cuag 100%.
3. Q: Koj ntim khoom dab tsi?
A: Export Txheem Packing, Carton, hnab lossis raws li cov neeg muas zaub' cov tseev kom muaj.
Cim npe nrov: din934 txheej sab nrauv hexagon txiv ntseej, Suav teb, lwm tus neeg, hoobkas, lag luam, customized, lag luam wholesale, luv nqi, quotation, tsis tshua muaj nqe, hauv Tshuag, dawb coj mus kuaj
